Peristaltic Pump-style Semi-automatic Liquid Filling Machine
Peristaltic pump-style semi-automatic liquid filling machine
Innovation Helps you better development, win more market.
Filling Machine Product Description:
xjjx10wm Our company products include:Oil filling machine,Liquid filling machine,Paste filling machine,ect.
Name Type: peristaltic pump-style semi-automatic liquid filling machine BT300-1F-type
Main use
May be filling the vast types of liquid filling, including high viscosity liquids. Such as: pharmaceuticals, chemicals, oils, cosmetics, food and other non-granulated liquid; filling with high precision, suitable for laboratory use.
Specifications
Speed range: 1 ~ 300rpm, positive inversion reversible
Speed mode: Continuous adjustment rotary encoder
Display: 128 * 64 dot matrix type LCD can display flow rate and speed are two ways to switch between displays
The allocation of frequency: 1 ~ 999 times
Allocation of fluid volume: 0.1ml ~ 99.9L
Time interval: 1 ~ 999 seconds
Back to the absorption angle: 0 ~ 360 (18 step)
Communication Interface: RS485
External control interface: start-stop control, direction control, speed control (0 ~ 5V, 0 ~ 10V, 4 ~ 20mA, 0 ~ 10KHz optional)
For Power: AC 220V 10%, 50Hz/60Hz (standard) AC 110V 10%, 50Hz/60Hz (optional)
Power consumption:
