the informations about spray autoclaveApplication Scope
This machine is mainly used for plastic packaging ,flexible packaging, tinplate ,cans ect.
Characteristic
1.The mode of automatic autoclave control
2.The spraying water fog will full of the whole space with the same temperature .leading the temperature to distribute uniformity.
3.The top of the world high-efficiency heat exchanger will be able to increase and drop the temperature of little spraying fog water rapidly and smoothly.
4.The most advanced of world circulation pump can use minimal power for maximum effect, power will be saved 27% than the same autoclaves.
5.Cooling water can be used repeatedly time after time, Low on the water quality requirements, Coastal areas of underground well water
6.Safe, stable ,reliable ,reliable and free adjustment process the anti-pressure control, which can ensure that the packaging will not deform.
7.High-fidelity process control ensure the batch production of food sterilization quality.suitable for different types and sizes of the packaging.
4.Basic Function
1.PLC program autoclavecontrol automatically,Touch screen order input.
2.Record the Curve Graphics process of temperaturepressure double-pen roll paper automatically.
3. Reminded the overtime of warm-up.
4.Electronics, machinery dual safety chain
5.Electronics, machinery double overpressure protection.
6.Electronic Super-temperature automatic protection.
7.Temperature Abnormal alarm.
8.Pressure Abnormal alarm.
9.Water level abnormal alarm.
10.Action abnormal alarm.
11.Air hammer silencer automatically.
12.Bactericidal flow direction automatic switching
13.Edit save Several of curing programmes(usually
14. Electronic temperature deviation correction.
15.Intellectualized temperature control, sterilization temperature control accuracy within
+-0.3
16.The speed of replacement water:.
17.Two-stage cooling.
18.Automatic autoclave soft water recovery system
size and weight :
Type Item
PL10
PL12
PL13
1
2
3
2
3
4
2
3
4
Inner diameter(mm)
1000
1000
1000
1200
1200
1200
1300
1300
1300
Length of canister(mm)
950
1900
2870
1900
2870
3820
1900
2870
3820
Total length(mm)
2500
3500
4500
3800
4800
5800
4000
5000
6000
Total width(mm)
2000
2000
2000
2300
2300
2300
2500
2500
2500
Total highness(mm)
3500
3500
3500
4000
4000
4000
4300
4300
4300
Net capacity(m3)
1.00
1.78
2.52
2.58
3.65
4.82
3.05
4.29
5.70
Weight(unload)(t)
2.8
3.2
3.6
3.5
4.0
4.5
4.0
4.3
4.6
Weight(load)(t)
3.4
3.8
4.3
4.2
5.0
5.8
